Specification
| Electrical Specification |
| Impedance |
75 Ohm |
| Frequency Range |
Up to 18GHz |
| Dielectric Withstand Voltage |
1000 Veff |
| Insulation Resistance |
10000 M-Ohm |
| Mechanical Specification |
| RoHS Compliant |
Yes |
| Mating Cycles Micro Musa |
5000 |
| Mating Cycles BNC |
500 |
| Weight |
32.21g |
| Mating Force |
10N max |
| Un-Coupling Force |
25N max |
| Environmental Specification |
| Operating Temperature |
-30 to +70 Deg C |
| IP Rating ( Mated ) |
IP30 |
| Materials |
| Centre Contact |
Beryllium Copper |
| Outer Contact |
Phosphor Bronze |
| Insulator |
PTFE |
| Centre Contact Plating |
Gold |
| Outer Contact Plating |
Nickel |
| Block |
POM |
| Pack Size |
1 |
Suitable for Cables in Group
N/A
No specific cables are associated with this connector
