Specification
| Electrical Specification | |
|---|---|
| Impedance | 50 Ohm |
| Frequency Range | 18GHz |
| Dielectric Withstand Voltage | 750 Veff |
| Insulation Resistance | 5000 M-Ohm |
| Mechanical Specification | |
| Design Standard | IEC 60169-15 |
| RoHS Compliant | Yes |
| Centre Contact Termination | Solder |
| Outer Contact Termination | Solder |
| Mating Cycles | 500 |
| Contact Retention | 27N min |
| Weight | 1.54g |
| Mating Force | 23Ncn |
| Un-Coupling Force | 23Ncn |
| Environmental Specification | |
| Operating Temperature | -55 to +155 Deg C |
| IP Rating ( Mated ) | IP40 |
| Materials | |
| Centre Contact | Beryllium Copper |
| Outer Contact | Brass |
| Insulator | PTFE |
| Centre Contact Plating | Gold |
| Outer Contact Plating | Gold |
| Pack Size | 1 |
Suitable for Cables in Group N/A
No specific cables are associated with this connector
Performance
| Performance Data available on request, please contact COAX |
Accessories
Downloads
| Interface Dimensions | C-RP-SMA |
| Data Sheet | 31 462 D3 1 1 REV A00 1 |
