Specification
| Specification |
| Impedance |
50 Ohm |
| Frequency Range |
DC 3GHz |
| Dielectric Withstand Voltage |
500 Veff |
| Insulation Resistance |
5000 M-Ohm |
| Mechanical Specification |
| RoHS Compliant |
Yes |
| Centre Contact Termination |
Solder |
| Outer Contact Termination |
Solder |
| Mating Cycles |
500 |
| Weight |
1.01g |
| Environmental Specification |
| Operating Temperature |
-55 to +155 Deg C |
| Materials |
| Center Contact |
Beryllium Copper |
| Outer Contact |
Phosphor Bronze |
| Insulator |
PTFE |
| Center Contact Plating |
Silver |
| Outer Contact Plating |
Nickel |
Suitable for Cables in Group
N/A
No specific cables are associated with this connector
Assembly
| Centre Contact |
Solder |
|
| Outer Contact |
Solder |
|
