Specification
| Electrical Specification |
| Impedance |
75 Ohm |
| Frequency Range |
Up to 12GHz |
| Dielectric Withstand Voltage |
1000 Veff |
| Insulation Resistance |
10000 M-Ohm |
| Mechanical Specification |
| RoHS Compliant |
Yes |
| Mating Cycles |
500 |
| Weight |
4.53g |
| Mating Force |
10N Max |
| Un-Coupling Force |
10N Max |
| Environmental Specification |
| Operating Temperature |
-55 to +155 Deg C |
| IP Rating ( Mated ) |
IP64 |
| Materials |
| Centre Contact |
Beryllium Copper |
| Outer Contact |
Brass |
| Insulator |
PTFE |
| Centre Contact Plating |
Gold |
| Outer Contact Plating |
Gold |
| Pack Size |
1 |
Suitable for Cables in Group
N/A
No specific cables are associated with this connector
